Our Projects
Real-world examples of our precision drafting bringing efficiency to building projects across multiple sectors.
Residential
High-End Residential
A detailed retrofit design for a historic home, carefully avoiding existing structural elements while ensuring even heat distribution.
Area Size
4,200 Sq Ft
System Type
Retrofit System
Challenge Solved
Adapting to varying floor depths and integrating with existing radiator circuits using precision manifold placement.
Commercial
Co-Working Complex
A fast-turnaround conversion from architect markups into full production drawings for an expansive commercial environment.
Area Size
12,000 Sq Ft
System Type
Commercial Hydronic
Challenge Solved
Organizing complex centralized manifolds efficiently across large open zones so interference with partition structures was completely eliminated.
Residential
Luxury Villa Layout
Complete hydronic underfloor heating system design mapping multiple highly customized zones with variable floor finishes.
Area Size
3,400 Sq Ft
System Type
Hydronic / Heat Pump
Challenge Solved
Compensating for high heat loss through full-height feature windows by intensifying pipe density near the perimeter, avoiding cold downdrafts.
Commercial
Modern Retail Space
Complex multi-zone routing designed for a high-traffic retail store, incorporating specific cooling and heating requirements.
Area Size
8,500 Sq Ft
System Type
Multi-Zone Routing
Challenge Solved
Balancing the system across expansive shop floors while accounting for high-density shelving and display units.
Industrial
Warehouse Facility
Large-scale industrial underfloor heating layout optimized for heavy machinery loads and massive open areas.
Area Size
18,000 Sq Ft
System Type
Industrial Heating
Challenge Solved
Designing continuous, ultra-long pipe runs to minimize joints under a polished concrete slab while maintaining consistent flow rates.
